3M GPH-060GF VHB Tape

3M GPH-060GF VHB Tape

  • Gray, 25 mil (0.6 mm), acrylic adhesive with a conformable, acrylic foam core
  • Fast and easy-to-use permanent bonding method provides high strength and long-term durability
  • Can replace mechanical fasteners (rivets, welding, screws) or liquid adhesives in appropriate applications
  • Additional Product Information

Description and Features

Product Description 3M™ VHB™ Tape GPH-060GF is a 0.025 in (0.6 mm) thick gray double-sided acrylic foam tape with a red polyethylene film liner. The conformable foam provides good contact between substrates even when they are slightly mismatched.
Applications Can replace traditional mechanical fasteners and liquid adhesives in challenging, high temperature applications Assembly of components before powder coat or liquid paint processes High operating temperature applications Stiffener to panel Panel to frame
Feature 1 Gray, 25 mil (0.6 mm), acrylic adhesive with a conformable, acrylic foam core
Feature 2 Fast and easy-to-use permanent bonding method provides high strength and long-term durability
Feature 3 Can replace mechanical fasteners (rivets, welding, screws) or liquid adhesives in appropriate applications
Feature 4 Excellent high temperature resistance (short term 450˚F) allows for bonding prior to powder coat or liquid painting processes
Feature 5 Using tapes could eliminate drilling, grinding, refinishing, screwing, welding
Feature 6 Virtually invisible fastening helps keep surfaces smooth; no unsightly rivet heads or weld marks
Feature 7 Closed-cell construction allows both bonding and sealing
Feature 8 Allows the use of thinner, lighter weight and dissimilar materials
Feature 9 Pressure sensitive adhesive bonds on contact to provide immediate handling strength

Specifications

Color Gray
Total Thickness 25 mils
Material/Backing Conformable Acrylic Foam (closed cell)
Adhesive Type Acrylic
Liner Red PE film with 3M™ VHB™ print
Tensile Strength 91 lbs/in²
Adhesive Strength 14 lb/in
Temperature Performance 450 °F
Repositionable N/A
Adhesion Level to HSE High
Adhesion Level to LSE Medium
High Temperature Yes
UNSPSC 31201505
Country of Origin Brazil
Origin Criterion N/A
Certification Indicator N/A
Qualification Method N/A
Cage Code 4AJG6
ECCN Number EAR99

Compliance

Storage Condition Humidity Controlled Storage (16C/60F TO 27C/80F & 40-60%RH)
Shelf Life 24 months
Return Policy 25% restocking fee
RoHS Status RoHS3 Compliant
REACH Status REACH Compliant
Prop 65 Compliance Prop 65 Compliant
CMRT CMRT Compliant
